Panamax's MR Family of products offers several layers of surge protection. Panamax's patented Automatic Voltage Monitoring (AVM) technology continuously monitors the incoming power. In case of an undervoltage or brownout (too little electricity) or an overvoltage (too much electricity) a flashing red lightning bolt will be displayed and power to the equipment is automatically turned off. When voltage returns to a safe level, power to the equipment is automatically reconnected.
The other layer of surge protection Panamax offers is our exclusive Protect or Disconnect technology. This ultra fast protection circuitry completely protects your equipment from surges such as lightning. When overwhelmed with extreme catastrophic events, Panamax permanently disconnects AC power to equipment. All Panamax products offer this core protection technology.
Protecting a complete system may sometimes require that signal wires coming out of the wall be protected as well. Panamax has you covered there too. Universal ultra low-loss coaxial protection (as well as LAN/Ethernet) protection prevents signal lines from carrying damaging surges while maintaining full high-definition and high-speed Internet signals to your equipment for your connected life.
- 9 PROTECTED & FILTERED POWER OUTLETS
- EXCLUSIVE AUTOMATIC VOLTAGE MONITORING (AVM)
- PROTECT OR DISCONNECT TECHNOLOGY
- USB CHARGING (0.5V/5V)
- LINEAR LEVEL 3 FILTRATION (2 TOTAL ISOLATED BANKS) WITH DEDICATED HIGH CURRENT OUTLET BANK (4 OUTLETS)
- ANTENNA, CABLE, OR SATELLITE, LAN AND TELCO SIGNAL PROTECTION
- ROTATING & DIMMABLE MEDIA LIGHTS ILLUMINATE EQUIPMENT
- 8 FT. POWER CABLE WITH LOW PROFILE PLUG
|Voltage Protection Rating (UL 1449 3rd Edition, 3,000A)||330V|
|Under-voltage shutoff||100V ±2V|
|Single Pulse Energy Dissipation||1575 Joules|
|Response Time||< 1ns|
|Protection Modes||L-N, L-G, N-G|
|Protect or Disconnect Circuitry||Yes|
|Over-voltage shutoff||135V ±2V|
|Nominal Discharge Current (UL 1449 3rd Edition)||3,000A|
|Maximum Current Rating||15A (1800W)|
|Line Voltage||120V, 50/60Hz|
|Initial Clamping Level||200V Peak, 141VRMS|
|Automatic Voltage Monitoring Circuit||Yes|
Linear Level 3 Noise Filtration
|Bank 1 |
-70dB min. @ 100kHz
-65dB min. @ 250kHz
-45dB min. @ 500kHz
Max filtration: -80dB @ 150kHz
Bank 2 - High Current, Low Impedance
-50dB min. @ 100kHz
-60dB min. @ 250kHz
-45dB min. @ 500kHz
Max filtration: -63dB @ 250kHz
|Rack Ears||Not Included|
|Dimensions||6"l x 17"w x 1.75"h, 2.19"h with feet|
|Clamping Level||62V ± 6V @ 1 mA|
|Wires Protected||2 Wires, 1 Pair (4, 5)|
Universal Coax Protection
|Insertion Loss||< 0.5 dB|
|HD 1080 i/p Ready||Yes|
|Frequency Range||0 MHz - 2.2 GHz|
|Connections||Female "F", Gold Plated|
